FEATURES

FMPC101-J-4G128G

System
Parameters

CPU

Intel® CeleronTM J6412

Frequency

Quad Core Quad Thread/2.0GHz

Random Access
Memory(Ram)

Support DDR4-3200,1*SO-DIMM,Maximum support 32GB

Stockpile

1*SATA3.07P Connector/M.2 Connector,1*mSATA(3.0)

I/O Interface

Reticulation

2*Intel® 2.5Gbps PCle Ethernet Controller,RJ45

Sound Frequency

Realtek® HDA Codec,with MIC/Line-out and Amplifier

Usb

4*USB3.0, 2*USB2.0

Serial Port
(Computing)

4*RS-232,2*RS-232/RS-485(Terminals)

Expansion Slot

1*Mini PCle(4G/dual network port module,etc.),1*M.2(5G occupies one USB3.0 port),1*M2(WIFI+BT)

Other Interfaces

1*HDMI,1*DC-IN,1*Remote SW,1*SIM slot,1*DisplayPort

Physical
Characteristics

Dimension(W*H*D)

257mm×176mm×62mm

Opening Size(W*H)

249mm×162mm (1.40/1.90mm larger than actual opening size)

Net Weight

2.26kg

Operating
System

Operating System

Supports Windows10, Linux

Power Supply

Input Voltage

9-36VDC

Maximum Power
Consumption

20W

LCD Screen

Screen Type

10.1" Full HD TFT

Resolution

1280×800

Maximum Color

16.7MB

Be In A Poor Light

LED

Backlight
Mtbf(Hours)

1500hrs

Pixel Pitch

0.0565×0.1695

Luminance

400cd/m2

Contrast

800:1

Perspectives

(L)85/(R)85/(T)85/(B)85

Touch Screen

Touch Screen Type

10-contact capacitive touch screen,
  high-temperature five-wire resistive touch screen,no-touch

Transmittance

>85%

Controllers

USB port

Response Time
(Stylus)

<5ms

Surface Hardness

Mohs hardness 6H

Touch Life

250g/35,000,000 times

Stroke Life

250g/5,000,000 times

Environmental
parameters

Operating
Temperature

0~50°C(32~122°F)(Using normal temperature rated SSDs)

Customized Version

-20~60°C(-4~140°F)(Use of wide temperature rated SSDs)

Storage Temperature

-20~60°C(-4~140°F)

Relative Humidity

  10~95%RH@40C,non-condensing

Vibration
During  Operation

SSD applied:1.5 Grms,5~500 Hz,1 hr/axis

Emc

SSD applied:10G,half-sine wave

Shock At Work

CE/FCC Class B

Waterproofing

Front panel with IP65 protection rating
