FGate products are on-site intelligent data acquisition terminals in the industrial Internet of Things platform, which can easily realize remote data acquisition, remote download and remote maintenance of on-site equipment.
Download related documents and software
Availability:
In stock
Out of stock
Couldn't load pickup availability
| FEATURES | FGate-WiFi |
| Network Access | Ethernet,WiFi |
| CPU | 600MHz ARM Cortex-A8 |
| Storage | 128MB Flash+128MB DDR3 |
| Ethernet | 3 lines of 10M/100M Ethernet Port |
| SD Card | Available |
| USB Port | 1 USB Device 2.0, 1 USB Host 2.0 |
| IO Port | 2-line optoelectronic isolated digital input, 2-line relay output (Maximum 5A) |
| Serial Communication Ports | COM1:RS232/RS485/RS422,COM2:RS485,COM3:RS232 |
| Network Frequency Range | IEEE802.11b/g/n compatible WLAN IEEE 802.11e QoS Enhancement(WMM) |
| RTC | Built-in |
| Rated Power | <5W |
| Input Voltage | DC24V,working range:DC9V-28V |
| PowerProlection | Protect from thunder strike and surging |
| Power Interruption Tolerance | <3mS |
| Certification | CE,RoHS |
| Operating Temperature | -10-60℃ |
| Storage Temperature | -20-70℃ |
| Environmental Humidity | 10-90%RH (Non condensation) |
| Vibration Endurance | 10-25Hz(X/Y/Z direction 2G/30minutes) |
| Cooling | Natural cooling |
| Dimensions | 130mm×94mm×48mm(without antenna) |
| Weight | About 320g |
| Endosure Material | Engineering plastic |
| Transparent Transmission | / |
| VPN Transparent Transmission | Available |
| Data Monitoring | 300 points |
| Alarm Item | 100points |
| Historical Item | 30 points |
| Hisiorical Data Storage Duration | 180 days |
| Edge Computing | It supports scipts programming |
| Network Protocols | It supports over 400 industrial devices protocols |
| Management & Maintenance | Support import,export,and remote update of configuration files |
