FGate-4G-G

Regular price: $730.99
Sale price: $730.99
Regular price
Unit price: per

FGate products are on-site intelligent data acquisition terminals in the industrial Internet of Things platform, which can easily realize remote data acquisition, remote download and remote maintenance of on-site equipment.

Download related documents and software

Availability: In stock Out of stock

Product variants

Quantity

Description

FEATURES	FGate-4G-G
Network Access	Ethernet,4G
CPU	600MHz ARM Cortex-A8
Storage	128MB Flash+128MB DDR3
Ethernet	3lines of 10M/100M Ethernet Port
SD Card	Available
USB Port	1 USB Device 2.0,1 USB Host 2.0
IO Port	2-line optoelectronic isolated digital input,2-line relay output (Maximum 5A)
Serial Communication Ports	COM1:RS232/RS485/RS422,COM2:RS485,COM3:RS232
Network Frequency Range	LTE-FDD:B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/B19/B20/B25/B26/B28,LTE-TDD:B38/B39/B40/B41,WCDMA:B1/B2/B4/B5/B6/B8/B19 GSM:850/900/1800/1900MHz
RTC	Built-in
Rated Power	<5W
Input Voltage	DC24V,working range:DC9V-28V
PowerProlection	Protect from thunder strike and surging
Power Interruption Tolerance	<3mS
Certification	CE,RoHS
Operating Temperature	-10-60℃
Storage Temperature	-20-70℃
Environmental Humidity	10-90%RH (Non condensation)
Vibration Endurance	10-25Hz(X/Y/Z direction 2G/30minutes)
Cooling	Natural cooling
Dimensions	130mm×94mm×48mm(without antenna)
Weight	About 320g
Endosure Material	Engineering plastic
Transparent Transmission	NA
VPN Transparent Transmission	Available
Data Monitoring	500 points
Alarm Item	200 points
Historical Item	100 points
Hisiorical Data Storage Duration	180 days
Edge Computing	It supports scipts programming
Network Protocols	It supports over 400 industrial devices protocols
Management & Maintenance	Support import,export,and remote update of configuration filesSupport import,export,and remote update of configuration files
