FD310R

Regular price: $522.99
Sale price: $522.99
Regular price
Unit price: per

Industrial high quality components are used.Built-in installation structure without enclosure, compatible with serial port HMI. Various communication connections, supporting USB, SD card expanding connection. Compatible with powerful HMI configuration software. Reliable industrial design and high quality.

Download related documents and software

Availability: In stock Out of stock

Product variants

Quantity

Description

FEATURES	FD310R
Display	10.1" 16:9 TFT LCD
Resolution(WxH)	1024×600
Colors	24-bit
Brightness	400 cd/m²
Backlight	LED
LCD Life	50000 hours
Touch Panel	4 wires resistive touch screen
CPU	1GHz,dual core Cortex-A7
Memory	4GB eMMC+128MB DDR
RTC	Built in
Ethernet	1 way 10M/100M adaptive
USB Port	USB Slave 2.0 port1,USB Host 2.0 port1
Download Project	USB Host/USB Slave/Ethernet
COM Port	COM1:RS232/RS485/RS422 COM2:RS485 COM3:RS232
LCD viewing angle (T/B/L/R)	85'/85'/85'/85'
Power Consumption	<10W
Input Power	DC24V,working range DC9V~28V
Power Protection	Protected from thunderstrike and surging
Power Down Allowed	<5mS
CE &RoHS	Complied with EN61000-6-2:2005,EN61000-6-4:2007,RoHS, Surge Immunity:±1KV,EFT:±2KV,ESD:4KV,Air:8KV
Operating Temperature	0~50℃
Storage Temperature	-20~60℃
Anti-UV	Not suitable to work in strong ultraviolet light(such as direct sunlight)
Operating Humidity	10~90%RH(no condensate)
Vibration Endurance	10~25Hz(X,Y,Z direction 2G/30 minutes)
Cooling	Natural air cooling
Panel Cutout	236*144mm
Dimension	260170mm28mm
Weight	About 500g
